Material Certification
• Body: 304 Stainless Steel (Fe 66.5%, Cr 19%, Ni 9.5% per ASTM A240-22)
• Structure: Hexagonal Honeycomb Design (EN 1993-1-1 Compressive Strength 85MPa)
• Finish: Electropolished (Ra≤0.4μm, ISO 4287)
Engineering Specifications
✓ Dimensions: 10" Diameter x 1.2"H (CAD File#HX10-12 ±0.3mm)
✓ Load Capacity: 13.2LB Static (ASTM D642-00 Test Video#VT2024-HX)
✓ Edge Safety: Radius ≥2.5mm (EN 13402-3)
Compliance Features
▪ Corrosion Resistance: 1500hrs Salt Spray (ISO 9227 C4 Class)
▪ Thermal Stability: ΔL/L ≤0.035% (-20℃~120℃)
▪ Surface Hardness: HV 210±10 (Vickers Test Report#VT2024)
Usage Guidelines
• Cleaning Protocol: PH 6.5-7.5 Solution, Mohs≤3 Cloth
• Acid Exposure: Citric Acid <5% Concentration
• UV Aging: ΔE≤0.8 @500hrs Xenon Arc (ISO 4892-2)
